HFW13S-2STE1LF Real Image
Same model may have multiple batches, images only for reference.

HFW13S-2STE1LF

Part No HFW13S-2STE1LF
Manufacturer Amphenol
Catalog FFC, FPC (FlatFlexible) Connectors
Description CONN FFC FPC VERT 13POS 1MM SMD / 13 Position FFC, FPC Connector Contacts, Vertical - 1 Sided 0.039" (1.00mm) Surface Mount
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>FFC, FPC (Flat Flexible) Connectors
Mfr Amphenol ICC (FCI)
Series HFW
Package Tape & Reel (TR)
Product Status Obsolete
Flat Flex Type FFC, FPC
Mounting SMD (SMT)
Connector/Contact Type Contacts, Vertical - 1 Sided
Number of Positions 13
Pitch 0.039" (1.00mm)
Termination Solder
FFC, FCB Thickness 0.30mm, 0.33mm
Height Above Board 0.209" (5.30mm)
Cable End Type Straight, Tapered
Contact Material Phosphor Bronze
Contact Finish Tin
Housing Material Polyamide (PA6T), Nylon 6T, Glass Filled
Voltage Rating 100V
Temperature Range - Operating -55°C ~ 85°C
Material Flammability Rating UL94 V-0
Current Rating (Amps) 1A
Housing Color Black
Mating Cycles 30
Base Product Number HFW13S
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4051
Other Names HFW13S2STE1LF,609-1114-1,609-1114-2,609-1114-6
Standard Package 1,000
Win Source Part Number 1167154-HFW13S-2STE1LF
Ultra Librarian 3D Model Ultra Librarian HFW13S-2STE1LF CAD Model

Description

The HFW13S-2STE1LF connector is a 13-position FFC, FPC (Flat Flexible) connector with a pitch of 0.039” (1.00mm).

  • Connector Type: Board-to-board
  • Connector/Contact Type: Vertical-1 Sided
  • Housing Material: Polyamide (PA6T), Nylon 6T, Glass-Filled
  • Contact Material: Phosphor Bronze
  • Contact Finish: Tin
  • Voltage Rating: 100V
  • Height Above Board: 0.209” (5.30mm)
  • Operating Temperature: -55°C to 85°C
  • Packaging: Tape and Reel
  • Standard Package: 1,000 Connectors
  • Applications: Automotive, General Purpose, and Industrial
