Same model may have multiple batches, images only for reference.
D09P13A4GX00LF Real Image
Same model may have multiple batches, images only for reference.

D09P13A4GX00LF

Part No D09P13A4GX00LF
Manufacturer Amphenol
Catalog D - Sub Connectors
Description CONN D-SUB PLUG 9POS R/A SLDR / 9 Position D-Sub Plug, Male Pins Connector
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>D-Sub Connectors
Mfr Amphenol ICC (FCI)
Series Delta D
Package Tray
Connector Style D-Sub
Connector Type Plug, Male Pins
Number of Positions 9
Number of Rows 2
Mounting Type Through Hole, Right Angle
Shell Size, Connector Layout 1 (DE, E)
Contact Type Signal
Flange Feature Housing/Shell (4-40)
Termination Solder
Shell Material, Finish Steel, Tin-Nickel Plated
Contact Finish Gold
Contact Finish Thickness Flash
Material Flammability Rating UL94 V-0
Current Rating (Amps) 5A per Contact
Backset Spacing 0.409" (10.40mm)
Features Board Lock, Grounding Indents, Mounting Brackets
Voltage Rating 300V
Color Black
Dielectric Material Polybutylene Terephthalate (PBT)
Contact Material Brass
Temperature Range - Operating -55°C ~ 125°C
Base Product Number D09P13
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 609-1478
Standard Package 30
Win Source Part Number 1171921-D09P13A4GX00LF
Ultra Librarian 3D Model Ultra Librarian D09P13A4GX00LF CAD Model

Description

This Delta D connector series is a 9-position plug male pin that is designed for through-hole right-angle mounting.

  • Positions: 9
  • Connector Type: Plug, Male Pin
  • Mounting Type: Through Hole, Right Angle
  • Termination Type: Screw
  • Contact Material: Brass
  • Contact Finish: Gold
  • Voltage Rating: 300V
  • Current Rating: 5A per contact
  • Shell Material: Steel tin-nickel plated
  • Dielectric Material: Polybutylene Terephthalate (PBT)
  • Temperature Range: -55°C to 125°C
  • REACH: Unaffected
  • Backset Spacing: 0.409" (10.40mm)
  • Shell Size Connector Layout: 1 (DE, E)
