71292-002LF Real Image
Same model may have multiple batches, images only for reference.

71292-002LF

Part No 71292-002LF
Manufacturer Amphenol
Catalog D - SUB, D - SHAPED connectors
Description CONN SCA-2 PLUG 40P EDGE MT SLDR / 40 Position Plug Connector SCA-2 Board Edge, Straddle Mount Solder
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - D-Sub, D-Shaped Connectors - Centronics Connectors
Mfr Amphenol ICC (FCI)
Series 71292
Package Tray
Product Status Obsolete
Connector Style Center Strip Contacts
Connector Type Plug
Number of Positions 40
Number of Rows 2
Mounting Type Board Edge, Straddle Mount
Termination Solder
Type SCA-2
Contact Finish Gold, GXT™
Contact Finish Thickness 30.0µin (0.76µm)
Base Product Number 71292
Standard Package 100
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 1349815-71292-002LF
Ultra Librarian 3D Model Ultra Librarian 71292-002LF CAD Model

Description

This Amphenol ICC (FCI) Centronics connector is a D-sub, D-shaped connector with a type of SCA-2.

  • Type: SCA-2
  • Positions: 40
  • Connector Type: Plug
  • Rows: 2
  • Termination: Solder
  • Contact Finish: Gold with GXT
  • Contact Finish Thickness: 30.0µin (0.76µm)
  • Mounting: Board Edge, Straddle Mount
  • Connector Style: Center Strip Contacts
  • Package: 100
  • Flange Feature: Not Specified
  • ECCN: EAR99
  • MSL: 1 (Unlimited)
  • REACH: Affected
  • HTSUS: 8536.69.4040
  • Status: Obsolete
