The Minitek127® 1.27mm is a series of connectors manufactured by Amphenol ICC (FCI).

• Win Source Part Number: 1035571-20021121-00016C4LF
• Connector Type: Header
• Contact Gender: Male Pin
• Number of Positions: 16
• Positions Loaded: All
• Number of Rows: 2
• Termination Type: Solder
• Fastening Type: Push-Pull
• Package: Tape & Reel
• Voltage Rating: 125VAC
• Mated Stacking Heights: Not specified
• Ingress Protection: Not specified
• Material Flammability Rating: Not specified
• Applications: Not specified
• Standard Package: 600
• Mounting Type: SMD (SMT)
• Insulation Material: Thermoplastic
• Style: Board to Board
• Pitch - Mating: 0.050" (1.27mm)
• Contact Finish - Mating: Gold with a thickness of 10.0µin (0.25µm)
• Contact Finish - Post: Tin with a thickness of 50.0µin (1.27µm)
• Insulation Color: Black
• Shrouding: Unshrouded
• Row Spacing - Mating: 0.050" (1.27mm)
• Contact Length - Mating: 0.120" (3.05mm)
• Contact Length - Post: Not specified
• Overall Contact Length: Not specified
• Insulation Height: Not specified
• Contact Shape: Square
• Temperature Range - Operating: -55°C ~ 125°C
• Alternative Parts (Cross-Reference): 20021221-00016C4LF, 20021221-00012C4LF, M50-3600842, 20021221-00020C4LF, M50-3600642, M50-360074220021121-00016C4LF
• MSL Level: 1 (Unlimited)
• Current Rating (Amps): 1A per Contact
• REACH Status: REACH Affected
• HTSUS: 8536.69.4040
• Other Names: 609-3697-6, 2266-20021121-00016C4LF, 2002112100016C4LF, 609-3697-1, 609-3697-2, 10122279-316000RLF
• Base Product Number: 20021121
