Same model may have multiple batches, images only for reference.

10127721-041LF

Name: 10127721-041LF
Brand: Amphenol
SKU: 1190580
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	10127721-041LF
Manufacturer	Amphenol
Catalog	Rectangular Connectors
Description	CONN HEADER VERT 4POS 3MM / Connector Header Through Hole 4 position 0.118" (3.00mm)
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr	Amphenol ICC (FCI)
Series	Minitek® Pwr 3.0
Package	Tray
Connector Type	Header
Contact Type	Male Pin
Pitch - Mating	0.118" (3.00mm)
Number of Positions	4
Number of Rows	2
Row Spacing - Mating	0.118" (3.00mm)
Number of Positions Loaded	All
Style	Board to Cable/Wire
Shrouding	Shrouded - 4 Wall
Mounting Type	Through Hole
Termination	Kinked Pin, Solder
Fastening Type	Locking Ramp
Contact Length - Post	0.126" (3.20mm)
Insulation Height	0.433" (11.00mm)
Contact Shape	Square
Contact Finish - Mating	Tin
Contact Finish Thickness - Mating	100.0µin (2.54µm)
Contact Finish - Post	Tin
Contact Material	Copper Alloy
Insulation Material	Thermoplastic
Features	Board Guide
Temperature Range - Operating	-40°C ~ 105°C
Material Flammability Rating	UL94 V-0
Insulation Color	Black
Current Rating (Amps)	Varies by Wire Gauge
Voltage Rating	600VAC/DC
Contact Finish Thickness - Post	100.0µin (2.54µm)
Base Product Number	10127721
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
Other Names	10127721-041LF-ND,609-4859,2266-10127721-041LF
Standard Package	300
Win Source Part Number	1190580-10127721-041LF
Ultra Librarian 3D Model	Ultra Librarian 10127721-041LF CAD Model

Description

The Amphenol ICC (FCI) 10127721-041LF Minitek Pwr 3.0 Header Connector is a male pin header connector designed for use in board-to-cable/wire applications.

Type: Male Pin Header
Application: Board-to-Cable/Wire
Number of Positions: 4
Package: Tray
ECCN: EAR99
HTSUS: 8536.69.4040
Other Names: 10127721-041LF-ND, 609-4859, 2266-10127721-041LF
Base Product Number: 10127721
