The AMCC S3017A is a T1/E1/J1 transceiver designed for telecommunications applications. It functions as a single-chip interface for digital transmission lines, supporting multiple standards. This integrated circuit includes features like clock recovery, line equalization, and pulse shaping to ensure reliable data transmission and reception.

Applications

• Digital Cross-Connect Systems (DCS)
• Channel Banks
• Private Branch Exchanges (PBX)
• Voice over IP (VoIP) gateways
• Wireless Base Stations
• Digital Loop Carrier systems

Features

• Single-chip T1/E1/J1 transceiver
• Integrated clock recovery
• Line equalization
• Pulse shaping
• Jitter attenuation
• Loopback testing for diagnostics
• Low power consumption
• Compliance with ITU-T G.703, ANSI T1.403

Benefits

• Reduced component count
• Improved system reliability
• Simplified board design
• Enhanced signal integrity
• Lower power consumption
• Comprehensive diagnostics
• Interoperability with T1/E1/J1 infrastructure

Technical Specifications

The S3017A typically operates from a 3.3V power supply. It supports programmable transmit and receive parameters, optimizing performance for various line conditions. The clock recovery circuit uses a phase-locked loop (PLL) for accurate timing extraction. The device incorporates built-in self-test (BIST) capabilities for performance monitoring. The physical interface usually involves transformer coupling to the T1/E1/J1 line, and it handles clock slips and frame alignment issues. Package options generally include surface-mount packages.
