AZ2025-04S

Part No AZ2025-04S
Manufacturer Amazing
Catalog TVS - Diodes
Description TVS DEVICE LOW SPEED 4-CH 5V
Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Amazing
Package Strip
Product Status Active
Type Zener
Bidirectional Channels 4
Voltage - Reverse Standoff (Typ) 5V (Max)
Voltage - Breakdown (Min) 6.1V
Power Line Protection No
Applications General
Temperature Range - Operating -55°C ~ 125°C (TC)
Mounting Type Surface Mount
Package / Case SC-74A, SOT-753
Supplier Device Package SOT-23-5
Standard Package 10 pcs
REACH Status Vendor Undefined
Win Source Part Number 66627-AZ2025-04S
Ultra Librarian 3D Model Ultra Librarian AZ2025-04S CAD Model

Description

AZ2025-04S

The AZ2025-04S is a high-performance electronic component designed for a variety of applications including signal processing and power management. Its robust design ensures reliable performance in challenging environments, making it ideal for industrial and consumer electronics.

  • Applications:
    • Signal Processing Units
    • Power Management Systems
    • Consumer Electronics
  • Features and Benefits:
    • High Efficiency for Low Power Consumption
    • Compact Design for Space-Saving Solutions
    • Stable Performance in Harsh Conditions

Additional Details: The AZ2025-04S excels in minimizing power loss, thus enhancing the overall efficiency of electronic systems.
