Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Altera
Series Cyclone IV E
Number of LABs/CLBs 1395
Number of Logic Elements/Cells 22320
Total RAM Bits 608256
Number of I/O 153
Operating Supply Voltage 1.15 V ~ 1.25 V
Mounting SMD
Operating Temperature Range 0°C ~ 85°C (TJ)
Package 256-LBGA
Manufacturer Package 256-FBGA (17x17)
Win Source Part Number 773965-EP4CE22F17C7N
Popularity Medium
Supply and Demand Status Limited
Family Name EP4CE22
Introduction Date January 27, 2010
ECCN EAR99
Country of Origin Republic of Korea
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian EP4CE22F17C7N CAD Model

Description

The Altera EP4CE22F17C7N is a member of the Cyclone IV E series of integrated circuits (ICs).

  • I/Os: 153
  • LABs/CLBs: 1395
  • Logic Elements/Cells: 22320
  • RAM bits: 608256
  • Package: 256-LBGA
  • Estimated EOL Date: 2026
  • Supply and Demand Status: Limited
