Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Altera
Status Active
Number of LABs/CLBs 321
Number of Logic Elements/Cells 5136
Total RAM Bits 423936
Number of I/O 182
Supply Voltage - Operating 1.15 V to 1.25 V
Mounting SMD (SMT)
Temperature Range - Operating 0°C to 85°C (TJ)
Case / Package 256-FBGA (17x17)
Win Source Part Number 085661-EP3C5F256C8N
Family Name EP3C5
Introduction Date March 01, 2007
ECCN EAR99
Country of Origin Malaysia, Republic of Korea
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian EP3C5F256C8N CAD Model

Description

EP3C5F256C8N

The EP3C5F256C8N is a high-performance FPGA from Altera's Cyclone III family, designed to deliver optimized performance for cost-sensitive applications. Built with a 65 nm low-power process, it offers a superior balance of power consumption, size, and cost-effectiveness.

Features and Benefits

  • 65 nm low-power process technology delivering optimal power efficiency.
  • 256-pin FBGA package for flexibility and integration.
  • Embedded memory blocks support for efficient data storage and processing.
  • Advanced DSP capabilities suitable for signal processing applications.
  • High-speed connectivity for seamless data transfer.

Applications/Projects

  • Consumer electronics devices.
  • Motor control systems.
  • Automotive infotainment systems.
  • Wireless communication modules.
