ACS758LCB-050B-PFF-T

Part No ACS758LCB-050B-PFF-T
Manufacturer Allegro MicroSystems, LLC
Catalog HOT - SALES and EOL Components
Description Current Sensor Current Sensor AC/DC Current 5V Automotive 5-Pin Case CB-PFF Tube | SENSOR CURRENT HALL 50A AC/DC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Packaging Tube
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 50A
Output Ratiometric, Voltage
Sensitivity 40mV/A
Frequency DC ~ 120kHz
Linearity ±1%
Accuracy ±2%
Supply Voltage (V) 3V ~ 5.5V
Response Time 4μs
Maximum Supply Current 13.5mA
Temperature Range - Operating -40°C ~ 150°C
Polarization Bidirectional
Mounting Style Through Hole
Manufacturer Package 5-CB Formed Leads, PFF
Supplier Device Package 5-CB Module
Manufacturer Pack Quantity 34
MSL Level 1 (Unlimited)
Win Source Part Number 35784-ACS758LCB-050B-PFF-T
Family Name ACS758LCB
Introduction Date January 00, 1900
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2019
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ACS758LCB-050B-PFF-T CAD Model

Description

ACS758LCB-050B-PFF-T from Allegro MicroSystems, LLC is widely recognized as part of a current-sensing solution family used in power electronics, motor control, industrial equipment, battery systems, and protection circuits where isolated or contactless current measurement is important. Engineers often consider devices in this class when they need reliable current monitoring for control feedback, fault detection, or efficiency optimization without adding excessive insertion loss. In the HOT - SALES and EOL Components category, this part is especially relevant for maintenance teams, redesign planning, and sustaining engineering where continuity of supply matters as much as technical fit. The current lifecycle status for ACS758LCB-050B-PFF-T is information not available, so buyers should treat procurement planning carefully and confirm availability directly with authorized sources or the manufacturer. RoHS compliance information is also not available in the provided data; engineers should verify the latest compliance declaration, datasheet, and manufacturer documentation before production use.
