ACS733KLATR-40AB-T Real Image ACS733KLATR-40AB-T Real Image1 ACS733KLATR-40AB-T Real Image2
Same model may have multiple batches, images only for reference.
ACS733KLATR-40AB-T Real Image ACS733KLATR-40AB-T Real Image1 ACS733KLATR-40AB-T Real Image2
ACS733KLATR-40AB-T Real Image ACS733KLATR-40AB-T Real Image1 ACS733KLATR-40AB-T Real Image2
Same model may have multiple batches, images only for reference.

ACS733KLATR-40AB-T

Part No ACS733KLATR-40AB-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 40A 16SOIC / Current Sensor 40A 1 Channel Hall Effect, Differential Bidirectional 16-SOIC (0.295", 7.50mm Width)
Datasheet
ACS733KLATR-40AB-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers>Current Sensors
Mfr Allegro MicroSystems
Series Automotive, AEC-Q100
Package Tape & Reel
For Measuring AC/DC
Sensor Type Hall Effect, Differential
Current - Sensing 40A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 33mV/A
Frequency 1MHz
Linearity ±0.5%
Accuracy ±1.7%
Voltage - Supply 3.14V ~ 3.46V
Response Time 200ns
Current - Supply (Max) 35mA
Temperature Range - Operating -40°C ~ 125°C
Polarization Bidirectional
Mounting SMD (SMT)
Package / Case 16-SOIC (0.295", 7.50mm Width)
Supplier Device Package 16-SOIC
Base Product Number ACS733
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 620-1988-2,ACS733KLATR-40AB-T-ND,620-1988-1,620-1988-6
Standard Package 1,000
Win Source Part Number 982981-ACS733KLATR-40AB-T
Ultra Librarian 3D Model Ultra Librarian ACS733KLATR-40AB-T CAD Model

Description

The ACS733KLATR-40AB-T is a hall-effect current sensor designed for AC/DC current sensing applications in automotive systems.

  • Manufacturer: Allegro MicroSystems
  • Current Type: AC/DC
  • Application: Automotive Systems
  • Sensing Method: Hall Effect
  • Polarization: Bidirectional
  • Current-Sensing Range: 40A
  • Sensitivity: 33mV/A
  • Output: Ratiometric Voltage
  • Response Time: 200ns
  • Linearity: ±0.5%
  • Accuracy: ±1.7%
  • Operating Temperature Range: -40°C to 125°C
  • Voltage Supply: 3.14V to 3.46V
  • Package: 16-SOIC
  • Packaging: Tape and Reel
