The ACS722LLCTR-20AB-T is a current sensor IC manufactured by Allegro MicroSystems, LLC. It's designed to provide precise AC or DC current sensing for industrial, commercial, and communications systems. This device is based on the Hall-effect principle, offering galvanic isolation between the current being measured and the output signal. It is commonly used for monitoring current flow in power supplies, motor control, and load detection applications.

Applications

• Motor control systems.
• Power inverters.
• Overcurrent protection.
• Load detection.
• Power supplies.

Features

• Galvanic isolation.
• Low offset drift.
• High bandwidth.
• Analog output.
• Small surface mount package.

Benefits

• Precise current measurement.
• Enhanced safety and reliability.
• Simplified circuit design.
• Reduced component count.
• Improved system efficiency.

Additional Details
