A3909GLYTR-T

Part No A3909GLYTR-T
Manufacturer Allegro MicroSystems, LLC
Catalog PMIC - Full, Half - Bridge Drivers
Description Dual Full Bridge Motor Driver | IC MOTOR DRIVER PAR 10MSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Allegro MicroSystems, LLC
Packaging Reel
Output Configuration Half Bridge (4)
Applications DC Motors, General Purpose, Stepper Motors
Interface Logic
Load Type Inductive
Technology DMOS
Rds On 1.6Ohm LS + HS
Current - Output / Channel 1A
Supply Voltage (V) 4V ~ 18V
Load Voltage (V) 4V ~ 18V
Temperature Range - Operating -40°C ~ 150°C
Fault Protection Current Limiting, Over Temperature
Mounting Style SMD
Manufacturer Package 10-TFSOP, 10-MSOP Exposed Pad
Supplier Device Package 10-MSOP-EP
Family Part Number A3909
Manufacturer Pack Quantity 1
MSL Level 2 (1 Year)
Win Source Part Number 1134589-A3909GLYTR-T
Manufacturer Homepage www.allegromicro.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name A3909
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian A3909GLYTR-T CAD Model

Description

The A3909GLYTR-T is an integrated circuit manufactured by Allegro MicroSystems, LLC.

  • Mounting Style: SMD
  • Applications: DC motors, general purpose, and stepper motors
  • Technology: DMOS
  • Interface: Logic
  • Current Output/Channel: 1A
  • Fault Protection: Current limiting and over temperature
  • Output Configuration: Half bridge (4)
  • Load Type: Inductive
  • Supply and Demand: Balance
  • ECCN: EAR99
  • Halogen-Free: Compliant
  • Estimated EOL Date: 2023
  • MSL Level: 2 (1 year)
  • Supply Voltage Range: 4V to 18V
  • Load Voltage Range: 4V to 18V
  • Rds On: 1.6Ohm LS + HS
