Same model may have multiple batches, images only for reference.

AT45DB161E-SHD-B

Name: AT45DB161E-SHD-B
Brand: Adesto Technologies
SKU: 843145
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	AT45DB161E-SHD-B
Manufacturer	Adesto Technologies
Catalog	Memory
Description	IC FLASH 16MBIT SPI 85MHZ 8SOIC / FLASH Memory IC 16Mbit SPI 85 MHz 8-SOIC
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Integrated Circuits (ICs) - Memory - Memory
Mfr	Adesto Technologies
Package	Tube
Product Status	Not For New Designs
Programmable	Verified
Memory Type	Non-Volatile
Memory Format	FLASH
Technology	FLASH
Memory Size	16Mbit
Memory Organization	528 Bytes x 4096 pages
Memory Interface	SPI
Clock Frequency	85 MHz
Write Cycle Time - Word, Page	8µs, 4ms
Voltage - Supply	2.5V ~ 3.6V
Temperature Range - Operating	-40°C ~ 85°C (TC)
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.209", 5.30mm Width)
Supplier Device Package	8-SOIC
Base Product Number	AT45DB161
Standard Package	90 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.32.0071
Win Source Part Number	843145-AT45DB161E-SHD-B
Ultra Librarian 3D Model	Ultra Librarian AT45DB161E-SHD-B CAD Model

Description

The 843145-AT45DB161E-SHD-B is a 16Mbit FLASH memory IC from Adesto Technologies.

Memory Type: Non-Volatile
Voltage Supply: 2.5V to 3.6V
Clock Frequency: 85 MHz
Write Cycle Time: 8µs (words), 4ms (pages)
Memory Interface: SPI
Memory Organization: 528 Bytes x 4096 pages
Package: 8-SOIC (0.209", 5.30mm Width), Surface Mountable
Operating Temperature: -40°C to 85°C
Status: Not-For-New-Design
