The ACT4455YH-T is a highly integrated, quad-output power management unit (PMU) from Active-Semi International Inc. It is designed to provide a complete power solution for a variety of applications, including portable devices, wearables, and embedded systems. The PMU integrates multiple DC-DC converters and LDO regulators, along with control and protection features, to optimize power efficiency and system performance.

Applications:

• Portable devices
• Wearable electronics
• Embedded systems
• IoT (Internet of Things) devices
• Handheld medical devices
• Smartphones and tablets

Features:

• Quad-Output: Provides four independent voltage rails to power different system components.
• High Efficiency DC-DC Converters: Integrated buck converters with high efficiency across a wide load range.
• Low Dropout (LDO) Regulators: Provides clean and stable power for sensitive analog circuits.
• I2C Interface: Allows for programmable output voltage and current limits.
• Dynamic Voltage Scaling (DVS): Enables voltage scaling to optimize power consumption based on system load.
• Power Sequencing: Ensures proper power-up and power-down sequencing to prevent system instability.
• Over-Voltage Protection (OVP): Protects the load from over-voltage conditions.
• Over-Current Protection (OCP): Protects the PMU from over-current conditions.
• Thermal Shutdown: Protects the device from overheating.
• Compact Package: Small footprint package for space-constrained applications.

Benefits:

• Simplified Design: Highly integrated solution reduces design complexity and BOM cost.
• Improved Efficiency: High efficiency converters and LDOs minimize power losses and extend battery life.
• Programmable Outputs: I2C interface allows for flexible voltage and current settings.
• Robust Protection: Comprehensive protection features ensure reliable operation and prevent system damage.
• Small Form Factor: Compact package saves board space.

Additional Details:

The ACT4455YH-T's individual outputs can be configured to different voltage levels via the I2C interface. The device also features a power-good indicator for each output, allowing the system to monitor the voltage levels. The PMU's internal LDOs are designed to provide low-noise power for analog circuits such as ADCs and sensors. The device incorporates soft-start circuitry to limit inrush current during startup. The ACT4455YH-T is available in a thermally enhanced package to ensure reliable operation at high ambient temperatures.

Refer to the device datasheet for detailed specifications, including input voltage range, output voltage ranges, switching frequencies, efficiency curves, and thermal characteristics. Also, refer to the application notes for recommended external component values and layout guidelines to achieve optimal performance.
