APAE1575R1840BADB1F-T

Part No APAE1575R1840BADB1F-T
Manufacturer Abracon LLC
Catalog RF Antennas
Description RF ANT 1.575GHZ CER PATCH PIN
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

RF Family/Standard Navigation
Frequency Group UHF (1GHz ~ 2GHz)
Frequency (Center/Band) 1.575GHz
Frequency Range 1.557GHz ~ 1.563GHz
Antenna Type Ceramic Patch
Number of Bands 1
VSWR 1.5
Gain 3.3dBic
Termination Pin
Mounting Type Adhesive
Height (Max) 0.181" (4.60mm)
Applications GPS
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1510665-APAE1575R1840BADB1F-T
Ultra Librarian 3D Model Ultra Librarian APAE1575R1840BADB1F-T CAD Model
