ABM8G-22.1184MHZ-4Y-T3 Abracon LLC – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

ABM8G-22.1184MHZ-4Y-T3

Part No ABM8G-22.1184MHZ-4Y-T3
Manufacturer Abracon LLC
Catalog Crystals
Description CRYSTAL 22.1184MHZ 10PF SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type MHz Crystal
Frequency 22.1184 MHz
Frequency Stability ±30ppm
Frequency Tolerance ±30ppm
Load Capacitance 10pF
ESR (Equivalent Series Resistance) 60 Ohms
Operating Mode Fundamental
Temperature Range - Operating -10°C ~ 60°C
Mounting Type Surface Mount
Case / Package 4-SMD, No Lead
Supplier Device Package 4-SMD (3.2x2.5)
Size / Dimension 0.126" L x 0.098" W (3.20mm x 2.50mm)
Height - Seated (Max) 0.039\
Package Tape & Reel
Supply and Demand Status Limited
Win Source Part Number 1527625-ABM8G-22.1184MHZ-4Y-T3
Ultra Librarian 3D Model Ultra Librarian ABM8G-22.1184MHZ-4Y-T3 CAD Model
