ABM3B-20.000MHZ-B2-T Real Image ABM3B-20.000MHZ-B2-T real image25242
Same model may have multiple batches, images only for reference.
ABM3B-20.000MHZ-B2-T Real Image ABM3B-20.000MHZ-B2-T real image25242
ABM3B-20.000MHZ-B2-T Real Image ABM3B-20.000MHZ-B2-T real image25242
Same model may have multiple batches, images only for reference.

ABM3B-20.000MHZ-B2-T

Part No ABM3B-20.000MHZ-B2-T
Manufacturer Abracon LLC
Catalog Crystals
Description CRYSTAL 20.0000MHZ 18PF SMD / 20 MHz ±20ppm Crystal 18pF 50 Ohms 4-SMD, No Lead
Datasheet
ABM3B-20.000MHZ-B2-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Crystals, Oscillators, Resonators>Crystals
Mfr Abracon LLC
Series ABM3B
Package Tape & Reel
Type MHz Crystal
Frequency 20 MHz
Frequency Stability ±50ppm
Frequency Tolerance ±20ppm
Load Capacitance 18pF
ESR (Equivalent Series Resistance) 50 Ohms
Operating Mode Fundamental
Temperature Range - Operating -20°C ~ 70°C
Mounting SMD (SMT)
Package / Case 4-SMD, No Lead
Dimension 0.197" L x 0.126" W (5.00mm x 3.20mm)
Height - Seated (Max) 0.043" (1.10mm)
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.60.0050
Other Names 535-9125-6,ABM3B20000MHZB2T,300-9125-1-ND,300-9125-2-ND,300-9125-1,535-9125-2,535-9125-1,300-9125-2
Standard Package 1,000
Win Source Part Number 993307-ABM3B-20.000MHZ-B2-T
Ultra Librarian 3D Model Ultra Librarian ABM3B-20.000MHZ-B2-T CAD Model

Description

The ABM3B series crystal oscillator manufactured by Abracon LLC is a high-performance MHz crystal oscillator that features a frequency of 20 MHz, a frequency tolerance of ±20ppm, and a load capacitance of 18pF.

  • Frequency: 20 MHz
  • Frequency Tolerance: ±20ppm
  • Load Capacitance: 18pF
  • Package: Tape and reel
  • Standard Package: 1000 units per package
  • Mounting Type: Surface mount
  • Height: 0.043" (1.10mm)
  • Operating Temperature: -20°C to 70°C
  • ESR: 50 Ohms
  • Frequency Stability: ±50ppm
  • Applications: Widely used in various electronic applications
  • ECCN: EAR99
