ABM10AIG-20.000MHZ-4Z-T3 Abracon LLC
Same model may have multiple batches, images only for reference.

ABM10AIG-20.000MHZ-4Z-T3

Part No ABM10AIG-20.000MHZ-4Z-T3
Manufacturer Abracon LLC
Catalog Crystals
Description CRYSTAL 20.0000MHZ 10PF SMD
Datasheet
ABM10AIG-20.000MHZ-4Z-T3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Win Source Part Number Cross
Manufacturer Abracon LLC
Category Crystals, Oscillators, Resonators Crystals
Type MHz Crystal
Frequency 20 MHz
Frequency Stability ±50ppm
Frequency Tolerance ±30ppm
Load Capacitance 10pF
ESR (Equivalent Series Resistance) 60 Ohms
Operating Mode Fundamental
Operating Temperature -40°C ~ 125°C
Win Source Part Number WS1305057-ABM10AIG-20.000MHZ-4Z-T3
Ultra Librarian 3D Model Ultra Librarian ABM10AIG-20.000MHZ-4Z-T3 CAD Model

Description

Features
• AEC-Q200 Qualified
• Automotive Grade 1: -40°C to +125°C
• Automotive Grade 0: -40°C to +150°C (Available Upon Request)
• TS16949 Production Line Certified
• PPAP Available Upon Request
• Hermetically Seam-sealed Ceramic Package
• RoHS/RoHS II Compliant and Pb free
