Same model may have multiple batches, images only for reference.
CHG-1005-001010-KEP Real Image
Same model may have multiple batches, images only for reference.

CHG-1005-001010-KEP

Part No CHG-1005-001010-KEP
Manufacturer 3M
Catalog Circular Connectors - Housings
Description CONN RCPT 5POS IDC 22-24AWG GOLD / 5 Position Rectangular Receptacle Connector IDC Gold 22-24 AWG
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Free Hanging, Panel Mount
Mfr 3M
Series CHG
Package Bulk
Connector Type Receptacle
Contact Type Female Socket
Number of Positions 5
Pitch 0.100" (2.54mm)
Number of Rows 1
Mounting Type Free Hanging (In-Line)
Cable Termination IDC
Wire Type Discrete or Ribbon Cable
Wire Gauge 22-24 AWG
Features Closed End
Contact Finish Gold
Contact Finish Thickness 30.0µin (0.76µm)
Color Gray
Base Product Number CHG
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4051
Other Names 5400774629,00054007746294,05400774629,54007746294,3M9071,7100262348,XP700009697,CHG-1005-001010-KEP-ND,7010348784,80610562342,CHG1005001010KEP
Standard Package 100
Win Source Part Number 1051318-CHG-1005-001010-KEP
Ultra Librarian 3D Model Ultra Librarian CHG-1005-001010-KEP CAD Model

Description

The 3M 1051318-CHG-1005-001010-KEP is a 5-position, gray connector receptacle with IDC termination.

  • Series: CHG series
  • Pitch: 0.100" (2.54mm)
  • Packaging: bulk with 100 pieces per package
  • Contact finish: gold contact finish
  • Contact finish thickness: 30.0µin (0.76µm)
  • Wire: 22-24 AWG wire
  • Wire types: discrete or ribbon cable wire types
  • ECCN: EAR99
  • HTSUS: 8536.69.4051
  • Alternative: CHG-1006-001010-KEP and CHG-1004-001010-KEP
