929838-01-03 Real Image
Same model may have multiple batches, images only for reference.

929838-01-03

Part No 929838-01-03
Manufacturer 3M
Catalog Circular Connectors - Housings
Description CONN HEADER R/A 6POS 2.54MM / Connector Header Through Hole, Right Angle 6 position 0.100" (2.54mm)
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr 3M
Series 929
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 6
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Board
Shrouding Unshrouded
Mounting Type Through Hole, Right Angle
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.235" (5.97mm)
Contact Length - Post 0.110" (2.79mm)
Insulation Height 0.215" (5.45mm)
Contact Shape Square
Contact Finish - Mating Tin-Lead
Contact Finish Thickness - Mating 100.0µin (2.54µm)
Contact Material Copper Alloy
Insulation Material Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Temperature Range - Operating -40°C ~ 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 2.5A
Base Product Number 929838
RoHS Status RoHS non-compliant
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 00076308023812,07630802381,3M156509-06,7630802381,76308023812,80001303108,929838-01-03-ND
Standard Package 1
Win Source Part Number 1022621-929838-01-03
Ultra Librarian 3D Model Ultra Librarian 929838-01-03 CAD Model

Description

The 3M 1022621-929838-01-03 is a male pin header connector that belongs to the category of electronic components.

  • Manufacturer: 3M
  • Market Status: Shortage
  • RoHS: Non-Compliant
