Same model may have multiple batches, images only for reference.
XC4020E-3HQ208C Real Image
Same model may have multiple batches, images only for reference.

XC4020E-3HQ208C

Part No XC4020E-3HQ208C
Manufacturer Xilinx Inc.
Catalog Embedded - FPGAs (Field Programmable Gate Array)
Description IC FPGA 160 I/O 208HQFP
Datasheet
XC4020E-3HQ208C Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Xilinx Inc.
Status Obsolete(EOL)
Number of LABs/CLBs 784
Number of Logic Elements/Cells 1862
Total RAM Bits 25088
Number of I/O 160
Number of Gates 20000
Supply Voltage - Operating 4.75 V to 5.25 V
Mounting SMD (SMT)
Temperature Range - Operating 0°C to 85°C (TJ)
Case / Package 208-PQFP (28x28)
Win Source Part Number 057657-XC4020E-3HQ208C
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian XC4020E-3HQ208C CAD Model

Description

The Xilinx Inc. XC4020E-3HQ208C is an obsolete (EOL) integrated circuit that features 160 I/Os, 784 LABs/CLBs, 1862 logic elements/cells, 25088 RAM bits, and 20000 gates.

  • I/Os: 160
  • LABs/CLBs: 784
  • Logic Elements/Cells: 1862
  • RAM Bits: 25088
  • Gates: 20000
  • Mounting: SMD (SMT)
  • Temperature Range: 0°C to 85°C (TJ)
  • Supply Voltage: 4.75 V to 5.25 V
