7447968 Wurth Electronics Inc
Same model may have multiple batches, images only for reference.

7447968

Part No 7447968
Manufacturer Wurth Electronics Inc
Catalog Fixed Inductors
Description FIXED IND
Datasheet
7447968 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr Wurth Electronics Inc
Series WE-MI
Product Status Active
Type Multilayer
Inductance 10 µH
Tolerance ±10%
Current Rating (Amps) 3 mA
Shielding Unshielded
DC Resistance (DCR) 1.85Ohm Max
Q @ Freq 30 @ 2MHz
Frequency - Self Resonant 17MHz
Temperature Range - Operating -55°C ~ 125°C
Inductance Frequency - Test 2 MHz
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Supplier Device Package 0603
Size / Dimension 0.063" L x 0.031" W (1.60mm x 0.80mm)
Height - Seated (Max) 0.039" (1.00mm)
Standard Package 4,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 547422-7447968
Ultra Librarian 3D Model Ultra Librarian 7447968 CAD Model

Description

The 547422-7447968 is a fixed inductor from the WE-MI series.

  • Series: WE-MI
  • Type: Multilayer inductor
  • Size: 0.063 inches (1.60mm) in length and 0.031 inches (0.80mm) in width
  • Inductance Value: 10μH
  • Tolerance: ±10%
  • Maximum Seated Height: 0.039 inches (1.00mm)
  • Mounting: Surface mount
  • Temperature Range: -55°C to 125°C
  • REACH Regulations: Unaffected
  • Application: Suitable for various inductor applications
