Same model may have multiple batches, images only for reference.

744778004

Name: 744778004
Brand: Wurth Electronics Inc
SKU: 857578
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	744778004
Manufacturer	Wurth Electronics Inc
Catalog	Fixed Inductors
Description	FIXED IND 4.7UH 2.32A 60MOHM SMD
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Inductors, Coils, Chokes - Fixed Inductors
Mfr	Wurth Electronics Inc
Series	WE-PD
Package	Tape & Reel
Product Status	Active
Type	Drum Core, Wirewound
Material - Core	Ferrite
Inductance	4.7 µH
Tolerance	±20%
Current Rating (Amps)	2.32 A
Current - Saturation (Isat)	4.2A
Shielding	Shielded
DC Resistance (DCR)	60mOhm Max
Frequency - Self Resonant	45MHz
Ratings	AEC-Q200
Temperature Range - Operating	-40°C ~ 125°C
Inductance Frequency - Test	1 kHz
Mounting Type	Surface Mount
Package / Case	Nonstandard
Size / Dimension	0.287" L x 0.287" W (7.30mm x 7.30mm)
Height - Seated (Max)	0.134" (3.40mm)
Standard Package	1,000 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.50.8000
Win Source Part Number	857578-744778004
Ultra Librarian 3D Model	Ultra Librarian 744778004 CAD Model

Alternative Products

Description

The WE-PD series is a range of fixed inductors designed for use in electronic circuits.

Model: 857578-744778004
Type: Drum core, wirewound
Shielded: Shielded
Size: 0.287" L x 0.287" W (7.30mm x 7.30mm)
Inductance: 4.7 μH
Maximum Seated Height: 0.134" (3.40mm)
Tolerance: ±20%
DC Resistance (DCR): 60mOhm Max
Operating Temperature Range: -40°C to 125°C
Current: 2.32A
Core Material: Ferrite
Self-Resonant Frequency: 45MHz
AEC-Q200 Rated: Yes
Package: Nonstandard
Manufacturer: Wurth Electronics Inc.
