The WAGO Corporation MCSMINI 1151916-734-366/037-000 is a plug and female socket type connector with six positions for mate and 12 positions for input.

• Product: 1151916-734-366/037-000
• Series: MCSMINI
• Manufacturer: WAGO Corporation
• Connector Type: Plug and Female Socket
• Positions (Mate): 6
• Positions (Input): 12
• Pitch: 0.138 inches
• Termination Style: Screwless Push-In Spring
• Current: Up to 10A
• Voltage (IEC): Up to 320V
• Voltage (UL): Up to 300V
• Housing Material: Polyamide (PA66) and Nylon 6/6
• Flammability Rating: UL94 V-0
• Color: Gray
• Actuation: Lever Actuated
• Retention: Retention Latches on Non-Wire Side
• Wire Gauge: 14-28 AWG or 0.08-1.5mm2
• Mounting: Free Hanging (In-Line)
• Insulation Height: 0.728 inches
