VBUS054CD-FHI real image VBUS054CD-FHI real image 2 VBUS054CD-FHI label picture
Same model may have multiple batches, images only for reference.
VBUS054CD-FHI real image VBUS054CD-FHI real image 2 VBUS054CD-FHI label picture
VBUS054CD-FHI real image VBUS054CD-FHI real image 2 VBUS054CD-FHI label picture
Same model may have multiple batches, images only for reference.

VBUS054CD-FHI

Part No VBUS054CD-FHI
Manufacturer Vishay
Catalog TVS - Diodes
Description 4-LINE BUS-PORT ESD-PROTECTION - FLOW THROUGH DESIGN / TVS DIODE 5VWM 13VC LLP2513
Datasheet
VBUS054CD-FHI Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Vishay
Packaging Reel - TR
Status Obsolete(EOL)
Type Steering (Rail to Rail)
Unidirectional Channels 4
STAND-OFF Voltage (Vwm) 5V (Max)
Minimum Breakdown Voltage 6.9V
Max Clamping Voltage 13V
Peak Pulse Current(Ippm) 3.5A (8/20μs)
Power Dissipation - Pd 45W
Power Line Protection Yes
Applications General Purpose
Capacitance @ Frequency 0.8pF @ 1MHz
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package LLP2513-11L
Win Source Part Number 057273-VBUS054CD-FHI
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name VBUS054CD-FHI
Introduction Date October 30, 2008
ECCN EAR99
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian VBUS054CD-FHI CAD Model

Description

The Vishay VBUS054CD-FHI is a steering TVS diode designed for general purpose applications.

  • Mounting: Surface-mount device
  • Channels: 4 unidirectional channels
  • Protection: Power line protection
  • Capacitance: 0.8pF @ 1MHz
  • Operating Temperature: -40°C to 125°C
  • Package: LLP2513-11L
  • Stand-off Voltage: 5V (Max)
  • Minimum Breakdown Voltage: 6.9V
  • Max Clamping Voltage: 13V
  • Peak Pulse Current: 3.5A (8/20μs)
  • Power Dissipation: 45W
  • Part Status: Obsolete (EOL)
  • Introduction Date: October 30, 2008
  • Popularity: High
  • Usage: Common-used part
