Same model may have multiple batches, images only for reference.
TDSG5150-MN Real Image
Same model may have multiple batches, images only for reference.

TDSG5150-MN

Part No TDSG5150-MN
Manufacturer Vishay
Catalog Display Modules - LED Character and Numeric
Description DISPLAY 7SEG 0.51" SGL GRN 10DIP / Display Modules - LED Character and Numeric Green 7-Segment 1 Character Common Anode 2.4V 20mA 0.689" H x 0.482" W x 0.252" D (17.50mm x 12.25mm x 6.40mm) 10-DIP (0.600", 15.24mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Optoelectronics>Display Modules - LED Character and Numeric
Manufacturer Vishay Semiconductor Opto Division
Packaging Bulk
Product Status Obsolete
Number of Characters 1
Size / Dimension 0.689" H x 0.482" W x 0.252" D (17.50mm x 12.25mm x 6.40mm)
Digit/Alpha Size 0.51" (13.00mm)
Display Type 7-Segment
Common Pin Common Anode
Color Green
Voltage - Forward (Vf) (Typ) 2.4V
Current - Test 20mA
Millicandela Rating 14mcd
Wavelength - Peak 565nm
Power Dissipation (Max) 550mW
Case / Package 10-DIP (0.600", 15.24mm)
Base Product Number TDSG5150
RoHS Status ROHS3 Compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.41.0000
Standard Package 400
Win Source Part Number 1331903-TDSG5150-MN
Ultra Librarian 3D Model Ultra Librarian TDSG5150-MN CAD Model

Description

The TDSG5150-MN is a green LED character and numeric display module from Vishay Semiconductor Opto Division.

  • Manufacturer: Vishay Semiconductor Opto Division
  • Package: 10-DIP (0.600", 15.24mm)
  • Common Pin: Common Anode
  • Millicandela Rating: 14mcd
  • Voltage Forward (Vf): 2.4V (typical) @ 20mA
  • Power Dissipation: 550mW
  • Peak Wavelength: 565nm
  • Display Type: 7-Segment
  • Characters: One
  • Digit/Alpha Size: 0.51" (13.00mm)
  • Status: Obsolete
  • ECCN: EAR99
  • MSL Level: 1 (unlimited)
  • REACH: Unaffected
  • HTSUS: 8541.41.0000
