Same model may have multiple batches, images only for reference.

SUM110P04-04L-E3

Name: SUM110P04-04L-E3
Brand: Vishay
SKU: 679848
Availability: InStock
Rating: 4.84 (48 reviews)

Get a Quote

Part No	SUM110P04-04L-E3
Manufacturer	Vishay
Catalog	Transistors - FETs, MOSFETs - RF
Description	P-Channel 40-V (D-S) 175 °C MOSFET
Datasheet	SUM110P04-04L-E3 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay
Series	TrenchFET
Packaging	Reel - TR
Channel Type Type	P
Technology	MOSFET
Drain Source Voltage	40V
Current - Continuous Drain (Id) @ 25°C	110A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Vgs(th) (Maximum) @ Id	3V @ 250μA
Gate Charge (Qg) (Maximum) @ Vgs	350nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds	11200pF @ 25V
Vgs (Maximum)	±20V
Power Dissipation (Maximum)	3.75W (Ta), 375W (Tc)
Rds On (Maximum) @ Id, Vgs	4.2 mOhm @ 30A, 10V
Operating Temperature Range	-55°C ~ 175°C (TJ)
Mounting	SMD
Manufacturer Package	TO-263 (D2Pak)
Package	TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number	1262536-SUM110P04-04L-E3
Manufacturer Homepage	www.vishay.com
Family Name	SUM110P04-04L
Introduction Date	September 08, 2003
ECCN	EAR99
Country of Origin	China, Taiwan
Estimated EOL Date	2019
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian SUM110P04-04L-E3 CAD Model

Description

The SUM110P04-04L-E3 is a P-channel MOSFET manufactured by Vishay in the TrenchFET series.

Product: SUM110P04-04L-E3
Manufacturer: Vishay
Series: TrenchFET
Drain-Source Voltage: 40V
Continuous Drain Current: 110A
Applications: Power supplies, motor control, and lighting
RoHS Compliant: Yes
Popularity: High
Supply and Demand: Balance
