SSB43L-E3/52T Real Image SSB43L-E3/52T Real Image
Same model may have multiple batches, images only for reference.
SSB43L-E3/52T Real Image SSB43L-E3/52T Real Image
SSB43L-E3/52T Real Image SSB43L-E3/52T Real Image
Same model may have multiple batches, images only for reference.

SSB43L-E3/52T

Part No SSB43L-E3/52T
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description Rectifier Diode Schottky 30V 4A 2-Pin SMB T/R / DIODE SCHOTTKY 30V 4A DO214AA
Datasheet
SSB43L-E3/52T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) 4A
Voltage - Forward (Vf) (Max) @ If 450mV @ 4A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 600μA @ 30V
Mounting SMD (SMT)
Case / Package DO-214AA (SMB)
Operating Temperature - Junction -65°C to 150°C
Win Source Part Number 066065-SSB43L-E3/52T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Industrial
Family Name SSB43L
Introduction Date November 13, 2003
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian SSB43L-E3/52T CAD Model

Description

The Vishay 066065-SSB43L-E3/52T is a Schottky diode that is designed to provide high efficiency and low power loss in a compact package.

  • Maximum DC Reverse Voltage: 30V
  • Forward Voltage: 450mV @ 4A
  • Current Rating: 4A
  • Current Leakage: 600μA @ 30V
  • Operating Temperature: -65°C to 150°C
  • Package: DO-214AA (SMB)
  • Family: SSB43L
  • Supply and Demand Status: Balanced
  • Applications: Power management and industrial
