Same model may have multiple batches, images only for reference.

SS8P3LHM3_A/H

Get a Quote

Part No	SS8P3LHM3_A/H
Manufacturer	Vishay
Catalog	Diodes, Rectifiers - Single
Datasheet	SS8P3LHM3_A/H Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products>Diodes - Rectifiers - Single
Mfr	Vishay General Semiconductor - Diodes Division
Series	Automotive, AEC-Q101, eSMP®
Package	Tape & Reel
Diode Type	Schottky
Voltage - DC Reverse (Vr) (Max)	30 V
Current - Average Rectified (Io)	8A
Voltage - Forward (Vf) (Max) @ If	570 mV @ 8 A
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr	200 µA @ 30 V
Capacitance @ Vr, F	330pF @ 4V, 1MHz
Mounting	SMD (SMT)
Package / Case	TO-277, 3-PowerDFN
Supplier Device Package	TO-277A (SMPC)
Operating Temperature - Junction	-55°C ~ 150°C
Base Product Number	SS8P3
Other Names	112-SS8P3LHM3_A/HCT,SS8P3LHM3_A/H,112-SS8P3LHM3_A/HDKR,112-SS8P3LHM3_A/HTR
Standard Package	1,500
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0080
Win Source Part Number	1281530-SS8P3LHM3_A/H
Ultra Librarian 3D Model	Ultra Librarian SS8P3LHM3_A/H CAD Model

Alternative Products

Description

The 1281530-SS8P3LHM3_A/H is a Schottky diode type electronic component manufactured by Vishay General Semiconductor - Diodes Division.

Part of: eSMP® series
Designed for: Automotive applications
Maximum DC Reverse Voltage: 30 V
Average Rectified Current: 8A
Voltage Forward: 570 mV @ 8 A
Reverse Recovery Time: less than 500 ns
Current Reverse Leakage @ Vr: 200 µA @ 30 V
Capacitance @ Vr, F: 330pF @ 4V, 1MHz
Operating Temperature Range: -55°C to 150°C
Package: TO-277, 3-PowerDFN
Supplier Device Package: TO-277A (SMPC)
Available in: Tape and reel packaging
Standard Package: 1,500
ECCN: EAR99
REACH: REACH unaffected
