SS3H10-E3/9AT Real Image SS3H10-E3/9AT real image6470 SS3H10-E3/9AT real image6471
Same model may have multiple batches, images only for reference.
SS3H10-E3/9AT Real Image SS3H10-E3/9AT real image6470 SS3H10-E3/9AT real image6471
SS3H10-E3/9AT Real Image SS3H10-E3/9AT real image6470 SS3H10-E3/9AT real image6471
Same model may have multiple batches, images only for reference.

SS3H10-E3/9AT

Part No SS3H10-E3/9AT
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 100V 3A DO214AB
Datasheet
SS3H10-E3/9AT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 800mV @ 3A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 20μA @ 100V
Mounting SMD (SMT)
Case / Package DO-214AB, (SMC)
Operating Temperature - Junction -65°C to 175°C
Win Source Part Number 030843-SS3H10-E3/9AT
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Power Management, Industrial
Ultra Librarian 3D Model Ultra Librarian SS3H10-E3/9AT CAD Model

Description

The Schottky diode from Vishay with the part number 030843-SS3H10-E3/9AT is a high-performance SMD (SMT) component designed for power management and industrial applications.

  • Maximum Reverse Voltage: 100V
  • Average Rectified Current: 3A
  • Forward Voltage: 800mV @ 3A
  • Reverse Leakage Current: 20μA @ 100V
  • Package: DO-214AB (SMC)
  • Recovery Speed: 200mA (Io)
  • Operating Temperature Range: -65°C to 175°C
  • Applications: Power management and industrial
