Same model may have multiple batches, images only for reference.

SS26HE3_A/I

Name: SS26HE3_A/I
Brand: Vishay
SKU: 845569
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	SS26HE3_A/I
Manufacturer	Vishay
Catalog	Diodes, Rectifiers - Single
Description	DIODE SCHOTTKY 60V 2A DO214AA / Diode 60 V 2A Surface Mount DO-214AA (SMB)
Datasheet	SS26HE3_A/I Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr	Vishay
Series	Automotive, AEC-Q101
Package	Tape & Reel
Product Status	Active
Technology	Schottky
Voltage - DC Reverse (Vr) (Max)	60 V
Current - Average Rectified (Io)	2A
Voltage - Forward (Vf) (Max) @ If	700 mV @ 2 A
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr	400 µA @ 60 V
Mounting Type	Surface Mount
Package / Case	DO-214AA, SMB
Supplier Device Package	DO-214AA (SMB)
Operating Temperature - Junction	-65°C ~ 150°C
Base Product Number	SS26
Standard Package	3,200 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0080
Win Source Part Number	845569-SS26HE3_A/I
Ultra Librarian 3D Model	Ultra Librarian SS26HE3_A/I CAD Model

Alternative Products

Description

The Vishay 845569-SS26HE3_A/I is a fast recovery rectifier diode designed for surface mount applications. It is part of the automotive AEC-Q101 series and features a fast recovery speed of less than 500ns and a current rating of greater than 200mA.

Automotive: AEC-Q101 series
Recovery Speed: less than 500ns
Current Rating: greater than 200mA
Voltage Rating: 60V
Diode Type: Schottky
Package: tape & reel
Standard Package: 3,200 pcs
Voltage Forward Drop: 700mV @ 2A
Reverse Leakage Current: 400 µA @ 60V
