SS14-E3/61T Vishay SS14-E3/61T Real Image1 SS14-E3/61T Real Image2 SS14-E3/61T label picture
Same model may have multiple batches, images only for reference.
SS14-E3/61T Vishay SS14-E3/61T Real Image1 SS14-E3/61T Real Image2 SS14-E3/61T label picture
SS14-E3/61T Vishay SS14-E3/61T Real Image1 SS14-E3/61T Real Image2 SS14-E3/61T label picture
Same model may have multiple batches, images only for reference.

SS14-E3/61T

Part No SS14-E3/61T
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 1A DO214AC
Datasheet
SS14-E3/61T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 500mV @ 1A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 200μA @ 40V
Mounting SMD (SMT)
Case / Package DO-214AC (SMA)
Operating Temperature - Junction -65°C to 125°C
Win Source Part Number 030816-SS14-E3/61T
Family Name SS14
Introduction Date June 24, 1998
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian SS14-E3/61T CAD Model

Description

The Vishay Schottky Diode is a highly reliable electronic component designed for a variety of applications.

  • Voltage: 40V
  • Average Rectified Current: 1A
  • Recovery Speed: 200mA (Io)
  • Reverse Leakage: 200μA @ 40V
  • Package: DO-214AC (SMA)
  • Supply and Demand: Sufficient
