SIR876ADP-T1-GE3 Vishay SIR876ADP-T1-GE3 Real Image SIR876ADP-T1-GE real image
Same model may have multiple batches, images only for reference.
SIR876ADP-T1-GE3 Vishay SIR876ADP-T1-GE3 Real Image SIR876ADP-T1-GE real image
SIR876ADP-T1-GE3 Vishay SIR876ADP-T1-GE3 Real Image SIR876ADP-T1-GE real image
Same model may have multiple batches, images only for reference.

SIR876ADP-T1-GE3

Part No SIR876ADP-T1-GE3
Manufacturer Vishay
Catalog FETs - Single
Description Trans MOSFET N-CH 100V 40A 8-Pin PowerPAK SO T/R / MOSFET N-CH 100V 40A PPAK SO-8
Datasheet
SIR876ADP-T1-GE3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Siliconix
Packaging Reel
Transistor Polarity N-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 100V
Id - Continuous Drain Current 40A
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Rds On (Maximum) at Id, Vgs 10.8mOhm at 20A, 10V
Gate Source Voltage(th) (Maximum) at Id 2.8V at 250μA
Gate Charge (Qg) (Maximum) at Vgs 49nC at 10V
Gate Source Voltage (Maximum) ±20V
Input Capacitance (Ciss) (Maximum) at Vds 1630pF at 50V
Power Dissipation (Maximum) 5W, 62.5W
Temperature Range - Operating -55°C ~ 150°C
Mounting Style SMD
Supplier Device Package PowerPAK SO-8
Manufacturer Package PowerPAK SO-8
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 720372-SIR876ADP-T1-GE3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name SiR876ADP
Introduction Date November 21, 2011
ECCN EAR99
Country of Origin China
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian SIR876ADP-T1-GE3 CAD Model

Description

The Vishay Siliconix SIR876ADP-T1-GE3 is an N-channel MOSFET with a drain-source breakdown voltage of 100V and a continuous drain current of 40A.

  • Drain-Source Breakdown Voltage: 100V
  • Continuous Drain Current: 40A
  • Package: PowerPAK SO-8
  • Power Dissipation: 5W, 62.5W
  • Gate Charge (Qg) @ Maximum Vgs: 49nC @ 10V
  • Input Capacitance (Ciss) @ Maximum Vds: 1630pF @ 50V
  • Rds On @ Maximum Id, Vgs: 10.8mOhm @ 20A, 10V
  • Drive Voltage: 4.5V
  • Maximum Vgs: ±20V
  • Popularity: Common-used
  • Supply and Demand Status: Limited
  • Alternative Parts: AON6224, TPH1400ANH, TPH1400ANH,L1Q(M, TPH1400ANH,L1Q
  • Manufacturer: Vishay Siliconix
