SFH6156-3T Real Image SFH6156-3T label picture SFH6156-3T real image SFH6156-3T real image5342 SFH6156-3T real image5343 SFH6156-3T Real Image1 SFH6156-3T Real Image2 SFH6156-3T Real Image3 SFH6156-3T Real Image4 SFH6156-3T Real Image5 SFH6156-3T Real Image6 SFH6156-3T Real Image7 SFH6156-3T Real Image8
Same model may have multiple batches, images only for reference.
SFH6156-3T Real Image SFH6156-3T label picture SFH6156-3T real image SFH6156-3T real image5342 SFH6156-3T real image5343 SFH6156-3T Real Image1 SFH6156-3T Real Image2 SFH6156-3T Real Image3 SFH6156-3T Real Image4 SFH6156-3T Real Image5 SFH6156-3T Real Image6 SFH6156-3T Real Image7 SFH6156-3T Real Image8
SFH6156-3T Real Image SFH6156-3T label picture SFH6156-3T real image SFH6156-3T real image5342 SFH6156-3T real image5343 SFH6156-3T Real Image1 SFH6156-3T Real Image2 SFH6156-3T Real Image3 SFH6156-3T Real Image4 SFH6156-3T Real Image5 SFH6156-3T Real Image6 SFH6156-3T Real Image7 SFH6156-3T Real Image8
Same model may have multiple batches, images only for reference.

SFH6156-3T

Part No SFH6156-3T
Manufacturer Vishay
Catalog Optoisolators - Transistor, Photovoltaic Output
Description DC-IN 1-CH Transistor DC-OUT 4-Pin PDIP SMD T/R / OPTOISOLATOR 5.3KV TRANS 4-SMD
Datasheet
SFH6156-3T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Vishay
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 5300Vrms
Minimum DC Current Transfer Ratio 100% @ 10mA
Maximum DC Current Transfer Ratio 200% @ 10mA
Switching Turn-On and Turn-Off Time 3μs, 2.3μs
Rise and Fall Time 2μs, 2μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 70V
Channel Output Current 50mA
Forward Voltage 1.25V
Continuous forward current- Max 60mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 4-SMD
Win Source Part Number 028257-SFH6156-3T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial, Communications & Networking, Sensing & Instrumentation
Family Name SFH6156
Introduction Date October 06, 2003
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian SFH6156-3T CAD Model

Description

The Vishay SFH6156 is a high-speed optocoupler that is used for signal isolation in industrial, communications, and networking applications.

  • Channels: One
  • Output Type: Transistor
  • Forward Voltage: 1.25V
  • Vce Saturation: 400mV
  • Isolation Voltage: 5300Vrms
  • Operating Temperature: -55°C to 100°C
  • Switching Turn-On Time: 3μs
  • Switching Turn-Off Time: 2.3μs
  • Rise Time: 2μs
  • Fall Time: 2μs
  • Maximum Output Voltage: 70V
  • Channel Output Current: 50mA
  • Continuous Forward Current: 60mA
  • Minimum DC Current Transfer Ratio: 100% @ 10mA
  • Maximum DC Current Transfer Ratio: 200% @ 10mA
  • Package: 4-SMD
  • Compliance: Halogen-free standards
