P6SMB400A-E3/52 Real Image P6SMB400A-E3/52 real image
Same model may have multiple batches, images only for reference.
P6SMB400A-E3/52 Real Image P6SMB400A-E3/52 real image
P6SMB400A-E3/52 Real Image P6SMB400A-E3/52 real image
Same model may have multiple batches, images only for reference.

P6SMB400A-E3/52

Part No P6SMB400A-E3/52
Manufacturer Vishay
Catalog TVS - Diodes
Description TVS DIODE 342VWM 548VC SMB
Datasheet
P6SMB400A-E3/52 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Vishay
Packaging Reel - TR
Status Active
Type Zener
Unidirectional Channels 1
STAND-OFF Voltage (Vwm) 342V
Minimum Breakdown Voltage 380V
Max Clamping Voltage 548V
Peak Pulse Current(Ippm) 1.1A
Power Dissipation - Pd 600W
Applications General Purpose
Temperature Range - Operating -65°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package DO-214AA (SMB)
Win Source Part Number 026345-P6SMB400A-E3/52
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian P6SMB400A-E3/52 CAD Model

Description

The Vishay P6SMB400A-E3/52 is a high-performance zener diode from Vishay. This device is designed for use in a wide range of applications, including circuit protection, power supplies, and lighting.

  • Features: High breakdown voltage and a low clamping voltage
  • Package: DO-214AA (SMB)
