DG409LEDY-T1-GE3 Real Image DG409LEDY-T1-GE3 real image24327
Same model may have multiple batches, images only for reference.
DG409LEDY-T1-GE3 Real Image DG409LEDY-T1-GE3 real image24327
DG409LEDY-T1-GE3 Real Image DG409LEDY-T1-GE3 real image24327
Same model may have multiple batches, images only for reference.

DG409LEDY-T1-GE3

Part No DG409LEDY-T1-GE3
Manufacturer Vishay
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC SWITCH SP4T X 2 23OHM 16SOIC / 2 Circuit IC Switch 4:1 23Ohm 16-SOIC
Datasheet
DG409LEDY-T1-GE3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Interface - Analog Switches, Multiplexers, Demultiplexers
Mfr Vishay
Package Tape & Reel
Product Status Active
Switch Circuit SP4T
Number of Circuits 2
On-State Resistance (Max) 23Ohm
Channel-to-Channel Matching (ΔRon) 1Ohm
Voltage - Supply, Single (V+) 3V ~ 16V
Voltage - Supply, Dual (V±) ±3.3V ~ 8V
Switch Time (Ton, Toff) (Max) 72ns, 47ns
Charge Injection -10pC
Channel Capacitance (CS(off), CD(off)) 5.5pF, 13.5pF
Current - Leakage (IS(off)) (Max) 1nA
Crosstalk -109dB @ 100kHz
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154", 3.90mm Width)
Supplier Device Package 16-SOIC
Base Product Number DG409
Standard Package 2,500 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 852068-DG409LEDY-T1-GE3
Ultra Librarian 3D Model Ultra Librarian DG409LEDY-T1-GE3 CAD Model

Description

The 852068-DG409LEDY-T1-GE3 is a dual-channel analog switch designed for interface applications.

  • Switch Circuit: 2 x SPST - NO
  • On-State Resistance (Max): 23Ohm
  • Voltage - Supply, Single (V+): 3V ~ 16V
  • Switch Time (Ton, Toff): 72ns, 47ns
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Surface Mount
  • Package / Case: 16-SOIC
