BAT46W-E3-08 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 150mA (DC)
Voltage - Forward (Vf) (Max) @ If 1V @ 250mA
Current - Reverse Leakage @ Vr 5μA @ 75V
Capacitance @ Vr, F 10pF @ 0V, 1MHz
Mounting SMD (SMT)
Case / Package SOD-123
Operating Temperature - Junction 125°C (Max)
Win Source Part Number 010966-BAT46W-E3-08
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Commercial
Family Name BAT46W
Introduction Date March 11, 2013
ECCN EAR99
Country of Origin China
Halogen Free Not Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian BAT46W-E3-08 CAD Model

Description

The BAT46W-E3-08 is an advanced Schottky diode designed for low forward voltage and high-speed switching, making it a perfect fit for efficient power management and signal processing applications.

Applications

  • High-efficiency power supplies
  • Signal processing circuits
  • RF applications

Features and Benefits

  • Low forward voltage: Minimizes power losses.
  • Fast reverse recovery: Enhances efficiency.
  • Compact form factor: Allows for flexible design options.
