82CNQ030ASM Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Semiconductor Diodes Division
Packaging Bulk
Status Obsolete
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 30V
Current - Average Rectified (Io) (per Diode) 40A
Voltage - Forward (Vf) (Maximum) at If 550mV at 80A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage at Vr 5mA at 30V
Operating Temperature - Junction -55°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package D-61-8-SM
Supplier Device Package D-61-8-SM
Family Part Number 82CNQ030
Manufacturer Pack Quantity 400
MSL Level 1 (Unlimited)
Win Source Part Number 1133936-82CNQ030ASM
Manufacturer Homepage www.irf.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 82CNQ030ASM CAD Model

Description

The Vishay Semiconductor Diodes Division 82CNQ030ASM is a fast recovery Schottky diode pair with a maximum reverse voltage of 30V and a maximum forward voltage of 550mV @ 80A.

  • Reverse Voltage: 30V (max)
  • Forward Voltage: 550mV @ 80A (max)
  • Diode Configuration: Common Cathode
  • Average Rectified Current per Diode: 40A
  • Package: Through-hole D-61-8-SM
  • Operating Temperature: -55°C to 150°C
  • Status: Obsolete
  • Manufacturer Homepage: www.irf.com
  • Package Quantity: 400
