1N4148W-E3-08 Vishay 1N4148W-E3-08 real image9 1N4148W-E3-08 Real Image 1N4148W-E3-08 label picture 1N4148W-E3-08 real image
Same model may have multiple batches, images only for reference.
1N4148W-E3-08 Vishay 1N4148W-E3-08 real image9 1N4148W-E3-08 Real Image 1N4148W-E3-08 label picture 1N4148W-E3-08 real image
1N4148W-E3-08 Vishay 1N4148W-E3-08 real image9 1N4148W-E3-08 Real Image 1N4148W-E3-08 label picture 1N4148W-E3-08 real image
Same model may have multiple batches, images only for reference.

1N4148W-E3-08

Part No 1N4148W-E3-08
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 75V 150MA SOD123
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 75V
Current - Average Rectified (Io) 150mA
Voltage - Forward (Vf) (Max) @ If 1.2V @ 100mA
Reverse Recovery Time (trr) 4ns
Current - Reverse Leakage @ Vr 100μA @ 100V
Capacitance @ Vr, F 4pF @ 0V, 1MHz
Mounting SMD (SMT)
Case / Package SOD-123
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 005297-1N4148W-E3-08
Family Name 1N4148W
Introduction Date December 23, 1998
ECCN EAR99
Country of Origin China
Halogen Free Unknown
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Signal Processing
Ultra Librarian 3D Model Ultra Librarian 1N4148W-E3-08 CAD Model

Description

Product Description

The 1N4148W-E3-08 is a high-speed silicon switching diode, offering exceptional performance for numerous applications. With its efficient design, it meets the demands of rapid electronic switching.

Features and Benefits

  • Excellent switching speed
  • High surge current capability
  • Compact and robust SOD-123 package
  • Stable forward voltage

Applications

  • Data line protection
  • Signal processing circuits
  • Logic switching
  • Voltage clamping in high-speed communications

The 1N4148W-E3-08’s durability and quick response make it an ideal component for circuits needing high efficiency and reliability.
