Same model may have multiple batches, images only for reference.
EKXJ451ELL560MLN3S Real Image
Same model may have multiple batches, images only for reference.

EKXJ451ELL560MLN3S

Part No EKXJ451ELL560MLN3S
Manufacturer United Chemi-Con
Catalog Aluminum Capacitors
Description CAP ALUM 56UF 20% 450V RADIAL / 56 µF 450 V Aluminum Electrolytic Capacitors Radial, Can 12000 Hrs @ 105°C
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors>Aluminum Electrolytic Capacitors
Mfr United Chemi-Con
Series KXJ
Package Bulk
Capacitance 56 µF
Tolerance ±20%
Voltage - Rated 450 V
Lifetime @ Temp. 12000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Polarization Polar
Ratings AEC-Q200
Applications Automotive
Ripple Current @ Low Frequency 585 mA @ 120 Hz
Ripple Current @ High Frequency 1.4625 A @ 100 kHz
Lead Spacing 0.295" (7.50mm)
Dimension 0.630" Dia (16.00mm)
Height - Seated (Max) 1.240" (31.50mm)
Mounting Type Through Hole
Package / Case Radial, Can
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Other Names 565-3538,EKXJ451ELL560MLN3S-ND
Standard Package 500
Win Source Part Number 1180267-EKXJ451ELL560MLN3S
Ultra Librarian 3D Model Ultra Librarian EKXJ451ELL560MLN3S CAD Model

Description

This aluminum electrolytic capacitor is part of the KXJ series and is manufactured by United Chemi-Con.

  • Capacitance: 56 µF
  • Tolerance: ±20%
  • Application: Automotive
  • Package: 500 standard pieces
  • Mounting: Through-hole
  • Rated Voltage: 450 V
  • Lead Spacing: 0.295" (7.50mm)
  • Package Type: Radial, can
  • Diameter: 0.630" (16.00mm)
  • Ripple Current (Low Frequency): 585 mA @ 120 Hz
  • Ripple Current (High Frequency): 1.4625 A @ 100 kHz
