Same model may have multiple batches, images only for reference.
EKXJ401ELL560MU25S United Chemi-Con
Same model may have multiple batches, images only for reference.

EKXJ401ELL560MU25S

Part No EKXJ401ELL560MU25S
Manufacturer United Chemi-Con
Catalog Aluminum Capacitors
Description CAP ALUM 56UF 20% 400V RADIAL / 56 µF 400 V Aluminum Electrolytic Capacitors Radial, Can 12000 Hrs @ 105°C
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors - Aluminum Electrolytic Capacitors
Mfr United Chemi-Con
Series KXJ
Package Bulk
Product Status Active
Capacitance 56 µF
Tolerance ±20%
Voltage - Rated 400 V
ESR (Equivalent Series Resistance) -
Lifetime @ Temp. 12000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Polarization Polar
Ratings AEC-Q200
Applications Automotive
Ripple Current @ Low Frequency 495 mA @ 120 Hz
Ripple Current @ High Frequency 1.2375 A @ 100 kHz
Lead Spacing 0.295" (7.50mm)
Size / Dimension 0.571" Dia (14.50mm)
Height - Seated (Max) 1.043" (26.50mm)
Surface Mount Land Size -
Mounting Type Through Hole
Package / Case Radial, Can
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Win Source Part Number 1358185-EKXJ401ELL560MU25S
Ultra Librarian 3D Model Ultra Librarian EKXJ401ELL560MU25S CAD Model

Description

The KXJ series from United Chemi-Con is a high-quality aluminum electrolytic capacitor designed for automotive applications.

  • Capacitance: 56 µF
  • Voltage - Rated: 400 V
  • Tolerance: ±20%
  • Applications: Automotive
  • Ripple Current @ Low Frequency: 495 mA @ 120 Hz
  • Ripple Current @ High Frequency: 1.2375 A @ 100 kHz
  • Mounting Type: Through Hole
  • Package / Case: Radial, Can
  • Lead Spacing: 0.295" (7.50mm)
  • Size / Dimension: 0.571" Dia (14.50mm)
  • Lifetime @ Temp.: 12000 Hrs @ 105°C
  • AEC-Q200: Yes
  • Series: KXJ
  • Status: Active
