EKXJ161ELL471MMN3S Real Image
Same model may have multiple batches, images only for reference.

EKXJ161ELL471MMN3S

Part No EKXJ161ELL471MMN3S
Manufacturer United Chemi-Con
Catalog Aluminum Capacitors
Description CAP ALUM 470UF 20% 160V RADIAL
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors - Aluminum Electrolytic Capacitors
Mfr United Chemi-Con
Series KXJ
Package Bulk
Product Status Active
Capacitance 470 µF
Tolerance ±20%
Voltage - Rated 160 V
Lifetime @ Temp. 12000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Polarization Polar
Ratings AEC-Q200
Applications Automotive
Ripple Current @ Low Frequency 1.66 A @ 120 Hz
Ripple Current @ High Frequency 3.735 A @ 100 kHz
Lead Spacing 0.295" (7.50mm)
Size / Dimension 0.709" Dia (18.00mm)
Height - Seated (Max) 1.299" (33.00mm)
Mounting Type Through Hole
Package / Case Radial, Can
Standard Package 250 pcs
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0020
Win Source Part Number 852086-EKXJ161ELL471MMN3S
Ultra Librarian 3D Model Ultra Librarian EKXJ161ELL471MMN3S CAD Model

Description

The KXJ series aluminum electrolytic capacitor is specifically designed for automotive applications. It is manufactured by United Chemi-Con.

  • Capacitance: 470 µF
  • Voltage - Rated: 160 V
  • Tolerance: ±20%
  • Size / Dimension: 0.709" Dia (18.00mm)
  • Height - Seated (Max): 1.299" (33.00mm)
  • Operating Temperature: -40°C ~ 105°C
  • Lifetime @ Temp.: 12000 Hrs @ 105°C
  • Polarization: Polar
  • Mounting Type: Through Hole
  • Package / Case: Radial, Can
  • Series: KXJ
  • Rating: AEC-Q200
  • Packaging: Bulk
  • Standard Package: 250 pcs
  • Impedance: 0.188 Ohms @ 120Hz
