UM8611

Name: UM8611
Brand: Union Semiconductor
SKU: 387716
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	UM8611
Manufacturer	Union Semiconductor
Catalog	EMI/RFI Filters (LC, RC Networks)
Description	8-Line LC EMI Filter with TVS
Datasheet	UM8611 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Filters - EMI/RFI Filters (LC, RC Networks)
Mfr	Union Semiconductor
Package	Tape & Reel
Product Status	Active
Type	Low Pass
Filter Order	3rd
Technology	LC (Pi)
Number of Channels	8
Center / Cutoff Frequency	150MHz (Cutoff)
Attenuation Value	-24dB @ 800MHz, -41dB @ 2 ~ 5GHz
Resistance - Channel (Ohms)	10
Values	L = 17nH, C = 15pF
ESD Protection	Yes
Temperature Range - Operating	-40°C ~ 85°C
Applications	Data Lines for Mobile Devices
Voltage - Rated	5V
Mounting Type	Surface Mount
Package / Case	8-UFDFN
Size / Dimension	0.130" L x 0.051" W (3.30mm x 1.30mm)
Height	0.024" (0.60mm)
Standard Package	2 pcs
MSL Level	3 (168 Hours)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.39.0001
Win Source Part Number	387716-UM8611
Ultra Librarian 3D Model	Ultra Librarian UM8611 CAD Model

Alternative Products

Description

The 387716-UM8611 is a low pass EMI/RFI filter from Union Semiconductor. It is designed for data lines in mobile devices and comes in a compact 8-UFDFN package.

Cutoff Frequency: 150MHz
Filter Order: 3rd order
Attenuation: -24dB @ 800MHz and -41dB @ 2 ~ 5GHz
Resistance per Channel: 10 Ohms
Inductance: L = 17nH
Capacitance: C = 15pF
ESD Protection: Yes
Operating Temperature Range: -40°C to 85°C
