The ESD08V52D-C is a Transient Voltage Suppressor (TVS) diode designed to protect sensitive electronic components from electrostatic discharge (ESD) and other transient voltage events. Manufactured by UN Semiconductor INC, this device is specifically engineered to safeguard data and power lines in a variety of applications. It provides a balance between protection voltage and capacitance, making it suitable for general purpose ESD protection.

Applications:

• Cell Phones: Protecting I/O ports and power lines.
• Portable Devices: Safeguarding sensitive circuits in devices like smartphones and tablets.
• Wearable Electronics: ESD protection for smartwatches and fitness trackers.
• USB Interfaces: Protecting USB ports from ESD strikes.
• General Purpose I/O Protection: Protecting various input/output lines from transient voltages.

Features:

• Low Clamping Voltage: Clamps transient voltages to a safe level, preventing damage to protected components.
• Fast Response Time: Quickly responds to ESD strikes, minimizing the risk of damage.
• Low Capacitance: Minimizes signal distortion in data lines.
• Small Package Size: Allows for easy integration in space-constrained applications.
• RoHS Compliant: Complies with Restriction of Hazardous Substances (RoHS) directive.

Benefits:

• Enhanced ESD Protection: Protects electronic components from ESD damage, improving device reliability.
• Improved System Reliability: Reduces the risk of system failures due to ESD events.
• Minimized Downtime: Prevents equipment downtime and repair costs associated with ESD damage.
• Increased Product Lifespan: Extends the lifespan of electronic devices by protecting them from voltage transients.
• Cost-Effective: Provides an economical solution for ESD protection.

Additional Details:

The ESD08V52D-C has a typical breakdown voltage around 9V and a clamping voltage suited for protecting 5V circuits. Its small form factor and low capacitance make it a good choice for various applications. The device is also compliant with RoHS standards. This TVS diode is an effective solution for protecting sensitive electronic components from electrostatic discharge and improving overall product reliability.

This part is listed as END-OF-LIFE by the manufacturer. Consider availability when designing this part into new products.
