BNCJ-MJ-PA TYCLON – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

BNCJ-MJ-PA

Part No BNCJ-MJ-PA
Manufacturer TYCLON
Catalog Coaxial Connectors (RF) - Adapters
Description In/Between Series Adaptors . This connector is suitable for various high-frequency applications. It features a impedance Mismatch, operates up to 200MHz(Max.), and has a rated voltage of AC 500V, ensures a high insulation resistance (100MΩ(Min.) at DC 500V), a low contact resistance (3 mΩ(Max.). Withstanding temperatures from -40 to +85°C. The contact is made of Phosphor Bronze/Gold Plating, while the body is Brass/Nickel Plating.
Datasheet
BNCJ-MJ-PA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Package Retail Package
Product Status Active
Adapter Type Jack to Jack
Conversion Type Between Series
Adapter Series BNC to M
Center Gender Female to Female
Convert From (Adapter End) BNC Jack, Female Socket
Convert To (Adapter End) M Jack, Female Socket
Impedance 50 Ohms
Style Straight
Mounting Type Panel Mount
Mounting Feature Flange
Fastening Type Bayonet Lock, Threaded
Frequency - Max 200MHz
Center Contact Plating Gold
Ultra Librarian 3D Model Ultra Librarian BNCJ-MJ-PA CAD Model
