7A-8.000MAAJ-T TXC CORPORATION 7A-8.000MAAJ-T Real Image
Same model may have multiple batches, images only for reference.
7A-8.000MAAJ-T TXC CORPORATION 7A-8.000MAAJ-T Real Image
7A-8.000MAAJ-T TXC CORPORATION 7A-8.000MAAJ-T Real Image
Same model may have multiple batches, images only for reference.

7A-8.000MAAJ-T

Part No 7A-8.000MAAJ-T
Manufacturer TXC CORPORATION
Catalog Oscillators
Description CRYSTAL 8.0000MHZ 18PF SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Crystals, Oscillators, Resonators - Crystals
Mfr TXC CORPORATION
Series 7A
Package Tape & Reel
Product Status Obsolete
Type MHz Crystal
Frequency 8 MHz
Frequency Stability ±30ppm
Frequency Tolerance ±30ppm
Load Capacitance 18pF
ESR (Equivalent Series Resistance) 80 Ohms
Operating Mode Fundamental
Temperature Range - Operating -20°C ~ 70°C
Mounting Type Surface Mount
Package / Case 2-SMD, No Lead
Size / Dimension 0.197" L x 0.126" W (5.00mm x 3.20mm)
Height - Seated (Max) 0.053" (1.35mm)
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.60.0050
Win Source Part Number 843092-7A-8.000MAAJ-T
Ultra Librarian 3D Model Ultra Librarian 7A-8.000MAAJ-T CAD Model

Description

The 843092-7A-8.000MAAJ-T is a MHz Crystal from the 7A series of crystals, oscillators, and resonators.

  • Mounting Type: Surface Mount
  • Package: 2-SMD, No Lead
  • Frequency: 8 MHz
  • Frequency Stability: ±30ppm
  • Frequency Tolerance: ±30ppm
  • ESR: 80 Ohms
  • Load Capacitance: 18pF
  • Operating Mode: Fundamental
  • Operating Temperature: -20°C to 70°C
  • Manufacturer: TXC CORPORATION
