AH225-S8G TriQuint Semiconductor AH225-S8G real image
Same model may have multiple batches, images only for reference.
AH225-S8G TriQuint Semiconductor AH225-S8G real image
AH225-S8G TriQuint Semiconductor AH225-S8G real image
Same model may have multiple batches, images only for reference.

AH225-S8G

Part No AH225-S8G
Manufacturer TriQuint Semiconductor
Catalog HOT - SALES and EOL Components (0 - A)
Description RF Amp Single Driver Amp 2.7GHz 5.5V 8-Pin SOIC / 1W High Linearity InGaP HBT Amplifier
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer TriQuint Semiconductor
Frequency 2700(MHz)
Mounting Surface Mount
Number of Channels 1
Package Type SOIC
Pin Count 8
Rad Hardened No
Operating Supply Voltage (Typ) 5(V)
Operating Supply Voltage (Min) 4.5(V)
Operating Supply Voltage (Max) 5.5(V)
Manufacturer's Type Driver Amplifier
Win Source Part Number 083318-AH225-S8G
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name AH225-S8G
Introduction Date February 09, 2009
ECCN 5A991.b
Country of Origin Thailand
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian AH225-S8G CAD Model

Description

AH225-S8G

The AH225-S8G is an advanced Hall effect sensor designed for enhanced magnetic field detection. Its robust engineering makes it suitable for diverse industry applications, delivering high performance and accuracy.

  • Applications:
    • Motor speed control
    • Position sensing
    • Home appliances
    • Security systems
  • Features and Benefits:
    • High precision magnetic sensitivity
    • Designed to sustain harsh environmental conditions
    • Energy efficient, with a low power requirement
    • Compact design ideal for space-constrained solutions
  • Additional Details:
    • Capable of detecting both north and south poles
    • Supports high-frequency operation
    • RoHS compliant for environmental protection
