TLP523 Toshiba Semiconductor and Storage TLP523 real image
Same model may have multiple batches, images only for reference.
TLP523 Toshiba Semiconductor and Storage TLP523 real image
TLP523 Toshiba Semiconductor and Storage TLP523 real image
Same model may have multiple batches, images only for reference.

TLP523

Part No TLP523
Manufacturer Toshiba Semiconductor and Storage
Catalog HOT - SALES and EOL Components (T)
Description programmable controllers dc-output module solid state relay
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Toshiba Semiconductor and Storage
Win Source Part Number 370506-TLP523
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Communications & Networking
Ultra Librarian 3D Model Ultra Librarian TLP523 CAD Model

Description

The Toshiba Semiconductor and Storage TLP523 Optoisolator is a high-performance component designed for use in communications and networking applications.

  • Typical forward voltage: 1.15V
  • Maximum DC forward current: 50mA
  • Ideal for: DC input applications.
  • Rise and fall time: not specified.
  • Output type: transistor
  • Channels: one channel.
  • Voltage isolation: not specified.
  • Package: 6-DIP package
  • Mountable: through-hole mountable.
