TLP185(GB-TPL,SE

Name: TLP185(GB-TPL,SE
Brand: Toshiba Semiconductor and Storage
SKU: 797032
Availability: InStock
Rating: 4.93 (1072 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TLP185(GB-TPL,SE
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Optoisolators - Transistor, Photovoltaic Output
Description	OPTOISO 3.75KV TRANS 6-SO 4 LEAD
Datasheet	TLP185(GB-TPL,SE Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Isolators
Manufacturer	Toshiba Semiconductor and Storage
Packaging	Reel package
Number of Channels	1
Voltage - Isolation	3750Vrms
Current Transfer Ratio (Minimum)	100% @ 5mA
Current Transfer Ratio (Maximum)	600% @ 5mA
Turn On / Turn Off Time (Typ)	3μs, 3μs
Rise / Fall Time (Typ)	2μs, 3μs
Input Type	DC
Output Type	Transistor
Output Voltage MAX	80V
Output Current per Channel	50mA
Voltage - Forward (Vf) (Typ)	1.25V
Current - DC Forward (If) (Maximum)	50mA
Vce Saturation (Maximum)	300mV
Operating Temperature Range	-55°C ~ 110°C
Mounting	SMD
Package	6-SMD (4 Leads), Gull Wing
Manufacturer Package	6-SO, 4 Lead
Win Source Part Number	797032-TLP185(GB-TPL,SE
Family Name	TLP185
ECCN	EAR99
Country of Origin	Japan, Thailand
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian TLP185(GB-TPL,SE CAD Model

Alternative Products

Description

The Toshiba Semiconductor and Storage TLP185(GB-TPL,SE is an isolator with a single transistor output.

Voltage Rating: 80V
Maximum Output Current Per Channel: 50mA
Package: 6-SMD (4 Leads), Gull Wing
Mounting: SMD
Current Transfer Ratio: 100% @ 5mA, 600% @ 5mA
Voltage Isolation: 3750Vrms
Operating Temperature Range: -55°C to 110°C
Family: TLP185
Category: Isolators
Demand: Popular
Estimated EOL Date: Yes
Alternative Parts: IS181A, IS181C, IS181GB
